KTM 690 SMC-R 2024

€13,399

The KTM 690 SMC R raises the bar in the supermotos stakes, thanks in part to a lightweight chassis, a legendary 690 LC4 motor and a sophisticated electronics package. Whether you express your tarmac-sliding talent on mountain roads or on the apexes of your favourite track, you’ll be drifting into the future with a maxed-out grin and your veins coursing with adrenaline. Handling is enhanced by the latest fully-adjustable WP APEX suspension, so all you have to worry about is focusing on the road ahead and twisting the throttle to the stoppers.

Categories: , , ,

Description

ENGINE

  • TORQUE73.5 Nm
  • TRANSMISSION6-speed
  • COOLINGLiquid cooled
  • POWER IN KW55 kW
  • STARTERElectric starter
  • STROKE80 mm
  • BORE105 mm
  • CLUTCHPASC (TM) slipper clutch, hydraulically actuated
  • CO2 EMISSIONS96 g/km
  • DISPLACEMENT692.7 cm³
  • EMSKeihin EMS with RBW, twin ignition
  • DESIGN1-cylinder, 4-stroke engine
  • FUEL CONSUMPTION4.1 l/100 km
  • LUBRICATIONForced oil lubrication with 2 oil pumps

CHASSIS

  • TANK CAPACITY (APPROX.)13.5 l
  • ABSBosch 9.1 MP (incl. Cornering-ABS and super moto mode)
  • FRONT BRAKE DISC DIAMETER320 mm
  • REAR BRAKE DISC DIAMETER240 mm
  • FRONT BRAKEBrembo four-piston radial fixed calliper, brake disc
  • REAR BRAKEBrembo single-piston floating calliper, brake disc
  • CHAIN520 X-Ring
  • FRAME DESIGNChrome-moly tubular space frame, powder-coated
  • FRONT SUSPENSIONWP APEX 48
  • GROUND CLEARANCE237 mm
  • REAR SUSPENSIONWP APEX with Pro-Lever linkage
  • SEAT HEIGHT892 mm
  • STEERING HEAD ANGLE63.6 °
  • SUSPENSION TRAVEL (FRONT)215 mm
  • SUSPENSION TRAVEL (REAR)240 mm
