Sale!
€23,199 €20,049
They say it’s lonely at the top. But that’s only because you’ve eaten your way to the sharp end of the pyramid. The KTM 1390 SUPER DUKE R takes its place as the undisputed Alpha of the NAKED pack, making its dominance felt with every brazen blip of its throttle.
TECHNICAL DETAILS
ENGINE
- TORQUE145 Nm
- TRANSMISSION6-speed
- BATTERY CAPACITY11.2 Ah
- COOLINGLiquid cooled with water/oil heat exchanger
- POWER IN KW140 kW
- STARTERElectric starter
- STROKE71 mm
- BORE110 mm
- CLUTCHPASC (TM) slipper clutch, hydraulically actuated
- CO2 EMISSIONS139 g/km
- DISPLACEMENT1350 cm³
- EMSKeihin EMS with RBW and cruise control, double ignition
- DESIGN2-cylinder, 4-stroke, V 75°
- FUEL CONSUMPTION5.9 l/100 km
- LUBRICATIONForced oil lubrication with 3 oil pumps
CHASSIS
- WEIGHT (WITHOUT FUEL)200.5 kg
- TANK CAPACITY (APPROX.)17.5 l
- ABSBosch 9.3 MP (with cornering ABS and SUPERMOTO ABS)
- FRONT BRAKE DISC DIAMETER320 mm
- REAR BRAKE DISC DIAMETER240 mm
- FRONT BRAKE2 x Brembo Stylema Monobloc four piston, radially mounted caliper
- REAR BRAKEBrembo twin-piston fixed calliper, brake disc
- CHAIN525 X-Ring
- FRAME DESIGNChrome-moly tubular space frame, powder-coated
- FRONT SUSPENSIONWP APEX 48
- GROUND CLEARANCE149 mm
- REAR SUSPENSIONWP APEX – Monoshock
- SEAT HEIGHT834 mm
- STEERING HEAD ANGLE65.3 °
- SUSPENSION TRAVEL (FRONT)125 mm
- SUSPENSION TRAVEL (REAR)140 mm
Description
THE BEAST, EVOLVED
