€4,899
The 24YM Dax will be available in the following colour options:
**NEW** Pearl Glittering Blue
Pearl Nebula Red
Pearl Cadet Grey
Description
| ENGINE | |
| Type | Air-cooled SOHC 4-stroke 2-valve |
| Displacement | 124cc |
| Bore x Stroke | 50.0 x 63.1mm |
| Compression Ratio | 10.0:1 |
| Max. Power Output | 6.9kW @ 7,000rpm |
| Max. Torque | 10.8Nm @ 5,000rpm |
| Noise Level (dB) | 69dB |
| Oil Capacity | 1 litre |
| FUEL SYSTEM | |
| Carburation | PGM-FI electronic fuel injection |
| Fuel Tank Capacity | 3.8 litres |
| Fuel Consumption | 66.7km/l |
| CO2 Emissions WMTC | 35 g/km |
| ELECTRICAL SYSTEM | |
| Battery | 12V 3.5Ah |
| DRIVETRAIN | |
| Clutch Type | Wet Multiplate and Automatic Centrifugal Clutch |
| Transmission Type | 4 speed rotary |
| FRAME | |
| Type | Press backbone frame |
| CHASSIS | |
| Dimensions (LxWxH) | 1,760 x 760 x 1,020mm |
| Wheelbase | 1,200mm |
| Caster Angle | 24.9° |
| Trail | 84mm |
| Seat Height | 775mm |
| Ground Clearance | 180mm |
| Turning radius | 2m |
| Kerb Weight | 107kg |
| SUSPENSION | |
| Type Front | Telescopic 31mm USD fork, 100mm axle travel |
| Type Rear | Twin shock, 120mm axle travel |
| WHEELS | |
| Type Front | 5-spoke cast aluminium |
| Type Rear | 5-spoke cast aluminium |
| Tyres Front | 120/70-12M/C 51L |
| Tyres Rear | 130/70-12M/C 56L |
| BRAKES | |
| Type Front | Single 220mm hydraulic disc with IMU-based ABS |
| Type Rear | Single 190mm hydraulic disc |
| ABS Type | Single Channel ABS |
| INSTRUMENTS & ELECTRICS | |
| Instruments | LCD |
| Headlight | LED |
| Taillight | LED |
