CMX500 Rebel – 25YM

Accessible, easy to ride and easy to live with, the CMX500 Rebel goes its own way but also acts as blank canvas, ready for whatever its owner’s imagination has in store. It receives further updates for 25YM to keep it fresh, plus a revised palette of standard paint choices, as well as super-cool exclusive colour for the ‘S’ Edition.
Categories: , ,

Description

Engine

  • Bore × Stroke (mm)67 x 66.8
  • CarburationPGM-FI
  • Compression Ratio10.7:1
  • Engine Displacement (cc)471cc
  • Engine TypeLiquid-cooled, DOHC
  • Max. Power Output34.0kW/8,500rpm
  • Max. Torque43.3Nm/6,000rpm
  • StarterElectric
  • C02 Emissions (g/km)84
  • Oil Capacity (Litres)3.2 litres

Wheels

  • Suspension Front41mm Telescopic forks
  • Suspension RearShowa with pro-link system
  • Tyre Size Front130/90-16M/C 67H
  • Tyre Size Rear150/80-16M/C 71H
  • Wheels Front16M/C x MT3.00
  • Wheels Rear16M/C x MT3.50

Dimensions and Weights

  • Battery Capacity (VAh)12V
  • Caster Angle28°
  • Dimensions (L×W×H) (mm)2,205 x 820 x 1,090
  • Fuel Tank Capacity (Litres)11.2
  • Fuel Consumption27.9 km/L (3.6 L/100km)
  • Ground Clearance (mm)125
  • Kerb Weight (kg)191
  • Seat Height (mm)690mm
  • Trail (mm)110
  • Wheelbase (mm)1490
  • Noise LevelLurban 74, Lwot 78

Transmission

  • ClutchWet multiplate, Assisted slipper clutch
  • Final DriveChain
  • Transmission Type6-speed

Instruments and Electrics

  • HeadlightsLED
  • InstrumentsDigital
  • Tail LightLED
